CNC TSHUAB DHOS Machining Raws

CNC TSHUAB DHOS MACHINERING Machining Raws li cov txheej txheem ntawm kev siv tshuab dhos cnc kom tshem tawm cov khoom siv los ntawm kev sib tw workpiece los tsim cov duab uas xav tau. Nov yog qee qhov tseem ceeb ntawm cov txheej txheem no:

Cov ntsiab cai tseem ceeb

• Lub workpiece yog clamped los ntawm chuck thiab tig los ntawm spindle.
• Ib lub cuab yeej Turret tuav ntau cov cuab yeej tej cov cuab yeej uas tau muab pub rau qhov ua haujlwm kom tshem cov khoom.

Hom kev ua haujlwm

1. Txoj siav: Tshem tawm cov khoom siv los ntawm cov cheeb tsam sab nraud ntawm lub workpiece los tsim cov kab cylindrical. Qhov no tuaj yeem muab faib ntxiv ua cov ntxhib thiab ua tiav tig.
2. Ntsia: Tsim ib qho chaw ncaj nraim saum npoo mus rau qhov chaw ua haujlwm lub axis.
3. Kev drilling: Tsim cov qhov nyob rau hauv workpiece.
4. Laj laj li: Nthuav dav cov qhov lossis kab noj hniav tsis pub dhau lub workpiece.
5. Thi: Txiav xov (sab nraud lossis sab hauv) mus rau qhov chaw ua haujlwm.
6. Parting / Txiav Tawm: Txiav qhov workpiece mus rau lwm daim.
7. Seej: Tsim cov kev txiav nqaim lossis cov chaw ua haujlwm ntawm qhov chaw ua haujlwm.
8. Lub zog: Tsim cov qauv qauv ntawm cov neeg ua haujlwm.

Hom CNC Lathes

• Kab rov tav cad lathes: Tus spindle yog mount horizontally. Lawv yog cov teeb tsa feem ntau thiab tsim nyog rau ntau yam kev siv.
• Ntsug c CNC lathes: Tus spindle yog mounted ntsug. Lawv feem ntau yog siv rau cov qauv loj thiab hnyav thiab cov khoom siv hnyav ua cov khoom siv nruab nrab ntawm lub ntiajteb txawj nqus yog ua raws li kev sib hloov.

Qhov Zoo

1. Kev nplig: CNC LATHES tuaj yeem txiav tawm thiab kho kom haum rau kev thev naus laus zis tsis tshua muaj zog, ua rau muaj kev kub siab- qhov chaw zoo.
2. Kev rov ua dua: Ib zaug programmed, cnc kws dhos tuaj yeem tsim kho tib qho ntau zaus nrog tib qhov tseeb, uas yog qhov tseem ceeb rau huab hwm coj ntau lawm.
3. Ua tau zoo: CNC LATHES ua haujlwm txuas ntxiv thiab txiav, txo cov nqi thiab cov nqi zog.
4. Yooj yooj: CNC Lathes tuaj yeem hloov kho rau cov qauv sib txawv thiab cov ntaub ntawv, pub ntau lawm cov khoom siv ntau ntawm cov ntu.
5. Kev ua yuam kev: Kev siv cov khoos phis tawm hauv koos pis tawj minimizes qhov kev pheej hmoo ntawm qhov yuam kev uas yuav tshwm sim nrog kev siv machining.

CNC Tig Chaw

Cov chaw xa khoom CNC yog ntau ntau yam tshuab uas feem ntau suav nrog cov qauv ntxiv tshaj qhov muaj peev xwm ua tau. Tej zaum lawv yuav muaj cov peev txheej siv tau, cov xim ntxiv rau ntau {{}}}}} chaw charting lossis milling), thiab automing cov pauv hloov.
