1, Sib tsoo txoj kev ntawm xov
Raws li cov ntaub ntawv sib txawv thiab kev pub mis ntawm kev sib tsoo log siv rau kev sib tsoo xov, muaj peb txoj kev ua haujlwm ntau:
1. Tib kab sib tsoo log, longitudinal pub: qhov kev ua tau zoo yog tsawg, tab sis qhov sib tsoo xov raug yog siab, uas yog tsuas yog siv rau ib thooj thiab me me batch ntau lawm.
2. Multi kab sib tsoo log, longitudinal pub: siab ntau lawm efficiency, feem ntau siv nyob rau hauv loj ntau lawm.
3. Ntau txoj kab sib tsoo log, txiav hauv pub: kev ua haujlwm siab ntau lawm, feem ntau siv hauv ntau lawm.
Rau cov xov nrog lub suab ntau dua 3 hli, cov xov yuav tsum tau ua ntej machined ua ntej sib tsoo; Rau cov xov nrog qhov deb ntawm tsawg dua 3 hli los ntawm cov ntsia hlau, cov xov tuaj yeem ncaj qha hauv av yam tsis muaj kev ua haujlwm ua ntej. Txoj kev no yog tsim rau machining workpieces nrog me me ntsia hlau pitch thiab xov ntev tsawg tshaj li qhov dav ntawm lub sib tsoo log.
2, Kev teeb tsa thiab siv cov cuab yeej sib tsoo tshuab
1. Kev txhim kho cov cuab yeej siv tshuab
(1) Xov sib tsoo yog nqa tawm ntawm ib qho tshwj xeeb xov grinder. Yog tias ua tiav ib daim thiab cov khoom me me ntawm cov xov hlau, cov cuab yeej siv tshuab yuav tsum tau muab tso rau hauv chav tsev kub tsis tu ncua nrog qhov ntsuas kub ntawm 20 ± 1 degree. Yog tias ua cov khoom loj ntawm cov xov, lub tshuab cuab yeej tuaj yeem ntsia tau rau hauv ib qho kev cob qhia zoo tib yam nrog cov xwm txheej zoo dua.
(2) Lub tshuab cuab yeej yuav tsum tau nruab rau ntawm lub hauv paus ruaj khov thiab nruab nrog kev tiv thaiv kev vibration ditch, deb ntawm qhov kev co sab nraud. Kab rov tav kev kam rau siab ntawm lub tshuab cuab yeej installation yuav tsum nyob rau hauv lub teev ntau yam ntawm lub tshuab cuab tam.
2. Siv cov cuab yeej siv tshuab
(1) Nws yuav siv sij hawm ib lub sij hawm rau lub tshuab cuab tam los ntawm Startup mus rau thermal stability. Nws yuav tsum tau idled rau ntau tshaj li ib nrab teev thaum lub sij hawm sib tsoo ntxhib thiab ntau tshaj 1 teev thaum lub sij hawm zoo sib tsoo; Thaum sib tsoo threads nrog siab roughness, nws yuav tsum tau idled rau ntau tshaj ib thiab ib nrab teev.
(2) Kev hloov siab ntawm qhov chaw tailstock yuav tsum tsim nyog, uas tuaj yeem loj dua rau cov workpieces tuab thiab luv thiab me me rau slender workpieces.
(3) Txhawm rau kom ntseeg tau qhov tseeb qhov tseeb ntawm qhov chaw, thaum sib tsoo ze rau qhov kawg ntawm qhov loj me, qhov kev hloov pauv yuav tsum tsis txhob loj dhau, feem ntau nyob rau hauv 0.01mm.
(4) Thaum sib tsoo zoo, kev sib tsoo yuav tsum tau nqa tawm los ntawm tailstock mus rau headstock kom deb li deb tau kom txo tau qhov yuam kev.
(5) Lub universal xov grinder yog nruab nrog ib txheej ntawm xov sib tsoo ntaus ntawv. Lub workpiece yog clamped nyob rau hauv plaub lub puab tsaig chuck, thiab lub ntsej muag kawg thiab puab lub qhov ntawm lub workpiece raug kho kom raug raws li qhov tseeb nrog ib lub rooj ua ntej sib tsoo. Thaum hnav lub log sib tsoo, lub kaum sab xis ntawm cov hniav sib tsoo tuaj yeem raug kho los ntawm kev sib tsoo ntawm cov ntawv nyias nyias.
(6) Sib tsoo ntau lub taub hau xov siv cov indexing chuck txuas nrog lub tshuab cuab yeej. Tus naj npawb ntawm cov hniav ntawm indexing chuck tuaj yeem xaiv raws li qhov xav tau.
(7) Thaum lub sij hawm sib tsoo, cov dej sib tsoo yuav tsum tau muab txau rau hauv qhov chaw sib tsoo kom ceev ceev ntawm cov khoom ua haujlwm thiab tshem tawm cov khoom khib nyiab. Nws yog ib qho tseem ceeb tshwj xeeb tshaj yog thaum sib tsoo xov nrog ntau kab sib tsoo log. Lub peev xwm ntawm kev sib tsoo cov kua tank yuav tsum loj txaus thiab nruab nrog cov kev pom zoo kom ntseeg tau tias qhov txias thiab ntxuav ntawm cov dej sib tsoo.
